Product Summary

The S-89431ACNC-HBVTFG is a CMOS type operational amplifier. The S-89431ACNC-HBVTFG features Rail-to-Rail I/O and an internal phase compensation circuit, and that can be driven at a lower voltage with lower current consumption than existing bipolar operational amplifiers. The S-89431ACNC-HBVTFG is a mini-analog series is a group of IC that incorporate a general purpose analog circuit in a small package. These features make this product the ideal solution for small battery-powered portable equipment. These features enable driving at a lower voltage (from 0.9V) and with lower current consumption (0.5 μA). The S-89431ACNC-HBVTFG is a single operational amplifier. The applications of the S-89431ACNC-HBVTFG include Cellular phones, PDAs, Notebook PCs, Digital cameras, Digital video cameras.

Parametrics

S-89431ACNC-HBVTFG absolute maximum ratings: (1)Power supply voltage, VDD: VSS -0.3 to VSS +7.0 V; (2)Input voltage, VIN: VSS -0.3 to VSS +7.0 (7.0 max.) V; (3)Output voltage, VOUT: VSS -0.3 to VDD +0.3 (7.0 max.) V; (4)Differential input voltage, VIND: ±5.5 V; (5)Output pin current, ISOURCE: 7.0 mA; ISINK: 7.0 mA; (6)Power dissipation, SOT-23-5, PD: 250 (When not mounted on board) mW; 600MW; (7)Operating temperature range, Topr: -40 to +85℃; (8)Storage temperature range, Tstg: -55 to +125℃.

Features

S-89431ACNC-HBVTFG features: (1)Lower operating voltage than the conventional general-purpose operational amplifiers: VDD = 0.9 to 5.5 V; (2)Low current consumption: IDD = 0.5 μA; (3)Wide I/O voltage range: VCMR = VSS to VDD ( Rail-to-Rail ); (4)Low input offset voltage: 5.0 mV (max.) (S-89431A); (5)No external capaciters required for internal phase compensation; (6)Lead-free products.
